Saft LS33600 batteries are created using a different type of chemistry, known as lithium thionyl chloride (Li-SOCI2). This chemistry perfectly suits high-energy and high-voltage requirements. These batteries are AA size batteries, and have a nominal voltage of 3.6V. The voltage is stable for most of the battery’s life, which makes it an ideal choice for professional electronics. LS33600 batteries have a low self-discharge rate for extended shelf life, and can operate effectively at extreme temperatures, between -60°C and 80°C.
This version of Saft LS33600 battery is the plain cell, and does not have axial wires, solder tags or PCB pins. These Saft LS33600 batteries are Made in France and have the silver collar around the positive top. Saft batteries produced in China have a green washer around the positive top. We hope this little tip helps you to identify the two types.
- Benefits
- High voltage response, stable
during most of the lifetime of the
application - Wide operating temperature
range (-60°C/85°C) - Easy integration in compact
system
Key features
- Stainless steel container
- Hermetic glass-to-metal sealing
- Built-in safety vent
- Finish with or without flat
positive end - Non-flammable electrolyte
- Compliant with IEC 60086-4
safety standard and
IEC 60079-11 intrinsic safety
standard - Underwriters Laboratories (UL)
Component Recognition
(File Number MH 12609)
Main applications
- Utility metering
- Automatic meter readers
- Buoys
- Measuring equipment
- Industrial applications
- Professional electronics
- Marine equipment
| Specification | Details |
|---|---|
| Dimensions (mm) | 33.4,61.3 |
| Range | Saft LTC |
| Pack Size | 1 |
| Weight | 90 g |
| Rechargeable | No |
| Chemistry | Lithium Thionyl Chloride |
| Voltage | 3.6 |
| Brand | Saft |
| Size | D |
| Capacity | 17Ah |
| Tariff Code | 85065000 |
| Country of Origin | France |
